node:b™ WW Engine Modular Architectural Lighting System

Add to Cart
Back to Top In Action Specs Downloads

node:b™ WW Engine

$459.99

SKU: 124344

  • 150W, WW (2800K) LED light source
  • Small in size, 10cm fixture diameter
  • Glass optical lens
  • High CRI: 97
  • 1-25Hz strobe effects
  • Adjustable LED refresh rates (1,000-8,000 Hz)
  • 16-bit dimming and 4x dimming curves
  • Selectable dimming speeds (low, medium, high)
  • Gobo pattern holder (gobos not included)
  • Multiple fan settings (full, auto, silent)
  • Dual mounting brackets for flexible positioning
  • 3-pin male/female XLR input & output
  • Available with black or white colored housing
Fast, Free Shipping on Orders $99+
Lenses are sold separately. Please select your lenses below before you check out.
- +
Add to Cart
Where Else to Buy
architectural
engine
theatrical

Compact & Quiet

Lightweight and airy at only 5.3lbs with quiet fan cooling, node:b™ seamlessly blends into the background.

Compact & Quiet

Lightweight and airy at only 5.3lbs with quiet fan cooling, node:b™ seamlessly blends into the background.

Product Summary

Compact, 2800K WW Lighting System

The ETL-listed node:b™ WW pairs a high-output 150W LED light engine with a variety of replaceable lens types to fit many applications ranging from gobo projection, to typical hard-edged profile use or even a smooth, vibrantly colored wash. This fixture is ideal for those in need of flexibility in their lighting.

Modular & Flexible Design

There are 3x lenses available for node:b™ fixtures with the choices of 15-30° or 25-50° profile zoom lenses with 4-blade manual shutters and focus, or a 16-65° Fresnel zoom lens. User-selectable dimming curves, dimming speed, and frequency mode settings are also accessible from its 4-button OLED control menu.

Specs

Optical

150W WW LED

Glass optical lens

CRI: 97

Flicker-free resolution

Gobo holder: 68.6mm outer, 24mm inner, 0.4mm thickness

Luminous Intensity:

WW Engine + 15-30° Profile Zoom Lens

(15° Narrow) 5,739 Lux @ 2.5m / 1,542 Lux @ 5m

(30° Wide) 1,257 Lux @ 2.5m / 632 Lux @ 5m

WW Engine + 25-50° Profile Zoom Lens

(25° Narrow) 2,223 Lux @ 2.5m / 550 Lux @ 5m

(50° Wide) 1,257 Lux @ 2.5m / 138 Lux @ 5m

WW Engine + 16-65° Fresnel Zoom Lens>

(16° Narrow) 1,598 Lux @ 2.5m / 433 Lux @ 5m

(65° Wide) 519 Lux @ 2.5m / 138 Lux @ 5m

Control

Protocol: DMX, RDM

3-pin DMX in/out

1/2/3/4 -channels

4-button menu with OLED display

DMX512, master/slave, standalone

Power

100-240VAC, 50-60 Hz

Consumption: 130W 1.42A, PF: .95

Heavy-duty, fixed power cord
