MystACL™ Z 10x 30W 4-in-1 RGBW LEDs

MystACL™ Z


SKU: 124238

  • 10x 30W OSRAM™ Ostar RGBW 4-in-1 LEDs, 50,000 hours
  • Fast and precise 3-60° zoomable beam angle
  • Single or dual pixel mapping capabilities via DMX
  • 8-16 bit motorized 210 degree tilt
  • 3-layer effects via DMX with configurable pixel sets & macros
  • Built-in macros with patterns + multiple color presets
  • Smooth electronic dimming, 0-100%
  • 1-10Hz strobe effects
  • Efficient low noise fan cooling system
  • 3/5-pin DMX + RJ45 input/output connections
  • PowerCON® TRUE1-compatible power input/output
  • Dual omega brackets with 1/4-turn fasteners
Fast, Free Shipping on Orders $99+
- +
Add to Cart
Where Else to Buy

Suggested Products

30W, 9+ Colors/Gobos, Ring Effects

Learn More

10x 3W WW LED Beams + RGB Effects

Learn More

4x Fixture Road Case

Learn More

224x super-bright 5050RGB/0.2W LED Wash + Pixel Effects

Learn More

Product Summary

RGBW LEDs + Zoom

MystACL™ Z is a high-performance LED bar loaded with 10* 30W OSRAM™ Ostar 4-in-1 RGBW LEDs. It offers DMX control with full pixel mapping capabilities, plus 3° to 60° zoom, creating effects that can range from a narrow angled light curtain to a wide angled wash.

Loaded with Features

It also features 210° motorized tilt (8-16 bit), unique 3-layer pixel set & macro effects, multiple built-in programs, color presets, 3/5-pin DMX + RJ45 input/output connections (Art-Net ready), and powerCON® TRUE1-compatible power input/output connections.



8-16 bit motorized 210° tilt

Flicker-free LEDs

Single or dual pixel mapping via DMX

3-layer effects via DMX

Built-in macros and color presets

Luminous intensity:

10,524 Lux @ 2.5M (narrow) 1,015 Lux @ 2.5M (wide)

6,105 Lux @ 5M (narrow) 241 Lux @ 5M (wide)


10x 30W OSRAM™ Ostar RGBW 4-in-1 LEDs, 50,000 hours

3-60° zoomable beam angle


Protocol: USITT DMX-512, Art-Net

DMX channels: 13/26/28 or 46-channel

5-button LCD control panel

Operating modes: DMX512, M/S, auto, sound active


100-240VAC, 50-60Hz

Power consumption: 261W, 2.26A, PF: .99

PowerCON™ TRUE1-compatible AC In/Out


2-year limited warranty
