Stiletto™ Ray-Z 7x 40W RGBW LED Wash/Beam FX

Stiletto™ Ray-Z


SKU: 124239

  • 7x 40W Osram™ Ostar RGBW 4-in-1 LEDs, 100,000 hours
  • Fast and precise zoomable beam angle (4.5°- 36°)
  • 8-16 bit smooth pan and tilt resolution
  • Pan: 540°/ Tilt: 200° with 3-phase motors
  • Automatic pan/tilt position correction
  • Full pixel mapping capabilities via DMX
  • Speed controllable shape macros + background color presets
  • Efficient low noise fan cooling system
  • Dual omega brackets with 1/4-turn fasteners
  • 5-pin DMX + RJ45 input/output connections
  • PowerCON® compatible power in/out connections
Fast, Free Shipping on Orders $99+
- +
Add to Cart
Where Else to Buy

Suggested Products

60W 4-in-1 LED + RGB Effects

Learn More

7x 15W RGBW LED Wash/Beam FX

Learn More

19x 15W 4-in-1 RGBW LEDs

Learn More

Product Summary

Pixel Mapping + Zoom

Stiletto™ Ray-Z is a feature-packed, professional moving head fixture fitted with 7x 40W OSRAM™ Ostar RGBW 4-in-1 LEDs with full pixel mapping capabilities via DMX, and it also offers ultra-fast and precise motorized zoom (4.5°- 36°) for narrow to wide moving beams.

Professional Features

It's 3-phase motors create smooth, quick movements (540° pan: 2.2s, 200° tilt: 1.2s) with automatic position correction, and it offers many pro features such as RGBW color mixing + pixel effects, auto and sound active programs, a variety of strobe effects, and more.



Luminous intensity:

43,675 Lux @ 2.5M (narrow), 2,023 Lux @ 2.5M (wide)

12,120 Lux @ 5M (narrow), 632 Lux @ 5M (wide)

5,324 Lux @ 7.5M (narrow), 277 Lux @ 7.5M (wide)

3,229 Lux @ 10M (narrow), 180 Lux @ 10M (wide)


7* 40W Osram Ostar RGBW 4-in-1 LEDs, 100,000 hours

RGBW color mixing

Full pixel mapping capabilities

Fast and precise zoomable beam angle (4.5°- 36°)

Flicker-free LEDs


8-16 bit smooth pan and tilt resolution

Pan: 540°/ Tilt: 200°

Automatic pan/tilt position correction


Protocol: USITT DMX-512, Art-Net, Kling Net, sACN

DMX channels: 15/18/38-channel modes

5-button LCD control panel

5-pin DMX + RJ45 input/output

Operating modes: DMX512, M/S, auto, sound active


90-250VAC, 50/60 Hz

Power Consumption: 324W, 2.92A, PF: .99

PowerCON™ compatible AC power In/Out connectors


2-year limited warranty

Dims & Weight

12.2" L x 8.6" W x 14.6" H

19.9 lbs
