SKU: 124310
Bundle Price
Add input/output cards to your order:
3.9mm Outdoor, SMD 1921 LEDs
9 Rack Space Processor / Splicer
Our Flagship Lighting Console
2.3M pixels (CVBS, VGA, DVI, HDMI, DP, SDI)
H Series is NovaStar's flagship all-in-one video splicing processor, designed specifically for fine-pitch LED applications. It is the first All-in-One splicer and controller in the industry, which greatly simplifies system integration. With the leading image processing technology in the industry, H series can give you an astonishing visual effect, truly making it the perfect solution for fine-pitch LED applications.
H2 offers a modular plug-in design, with a variety of connector modules available. It comes with the control card and power supply. A minimum of 1 additional input card, and 1 output card is required for full functionality.
| Available Cards | Description |
| H_4xDVI | 4x DVI Input Card |
| H_4xHDMI | 4x HDMI Input Card |
| H_1xHDMI2.0 | 1x HDMI2.0 Input Card |
| H_1xHDMI2.0+1xDP1.2 | 1x HDMI2.0 + 1x DP1.2 Input Card |
| H_2xRJ45 IP | 2x RJ45 IP Camera Input Card |
| H_4x3G SDI | 4x 3G-SDI Input Card |
| H_12G SDI Input Card | 1x 12G SDI Input Card |
| H_2xCVBS+2xVGA | 2x CVBS + 2x VGA Input Card |
| H_4xVGA | 4x VGA Input Card |
| H_16xRJ45+2xFiber | 16x Ethernet Output Port and 2x Optical Ports |
| H_2xRJ45+1xHDMI1.3 | 2x Ethernet and 1x HDMI1.3 for Monitoring |
| H_20xRJ45 | 20x Ethernet Port Output Card |
The industry's first ever, all-in-one splicing processors are here.
Watch Now ›H Series utilizes a full hardware slot structure with high-performance FPGA processing and ultra-speed crosspoint matrix switching technology, providing you with powerful signal processing capabilities.
Rack space: 2U
Minimum cards = 1 input, 1 output
Input cards: 4 max.
Input channels: 16 max.
Output cards: 2
Load capacity (4K card): 26m pixels
Max. layers: 32
Power cord
RJ45 Ethernet cable
Grounding cable
HDMI cable
Quick start guide
Certificate of approval
Safety manual
100-240VAC, 50/60Hz
Power consumption: 210W
10A-5A
Backup PS: optional
3-year warranty
19" L x 3.5" W x 18" H
34.4 lbs
