IRiS™ IP3

3.9mm Outdoor Video Panel

$1,699.99

IRiS™ IP3 Buy

3.9mm Outdoor LED Panel

IRiS™ IP3 is an ETL listed professional IP65 rated video panel with brilliant SMD 1921 LEDs, 3840Hz refresh rate, and a 3.9mm pixel pitch. It also has impressively high 4,500 nit brightness that can create perfect video images even in direct sunlight. They are designed for easy one man handling, and their sophisticated quick lock system makes setup a breeze. These panels also feature fast and accurate side locks that allow curved connections from 10° concave to 5° convex.

Quick + Easy Maintenance

The panels weigh in at under 21lbs thanks to their strong and lightweight CNC + cast aluminum frame, and module maintenance is tool-free and easy with their 4x magnetic-mount front/rear modules per panel. They can be controlled flawlessly with the Novastar® TB6 or VX4S LED display controllers, and each panel comes with a 3' etherCON® compatible interconnect, plus a 3' powerCON® TRUE1® compatible interconnect cable.

Main Features

* Panel Dimensions: 500×500x100mm * Pixel Pitch (mm): 3.9 * LED Type: SMD 1921 * Pixel Per Panel: 128×128 * Curvature: 10° concave, 5° convex maximum * Brightness (cd/m2): 4500 * Refresh Rate (Hz): 3840 * Panel Material: CNC + Cast Aluminum * Modules Per Panel: 4 * Module Dimensions: 250×250mm * Viewing Angle (H/V) (°): 140/120 * Send/Receive: NovaStar® Enhanced (Armor Series) * Power: Seetronic® Powerkon IP65 in/out * Data: Seetronic® Etherkon IP54 in/out * IP Rating (Front/Rear): IP65/IP54 * Certificate: cETLus | FCC | CE | RoHS

Product Specifications

Overview


Panel Material: CNC + Cast Aluminum

Front IP Rating: IP65

Rear IP Rating: IP54

Curve Hardware: Double-arm

Modules Per Panel: 4

Panels required for Native HD: 135

Rigging Options: IRiS-R2 & IP3-FLY1 + IRiS-R2 & IP3-FLY2 Bumpers, Ground Support, Wall Mounted

Max Rigged Height: 20 panels

Optical


Pixel Pitch (mm): 3.9

Native Resolution: 128x128

Pixels per Panel/m2: 16,384

LED Type: SMD 1921

Module Type: Magnetic, Universal

LED Lifetime (H): 100000

Brightness (cd/m2): 4500

Refresh Rate (Hz): 3840

Grayscale: 15-bit

Contrast Ratio: 4000:1

Color Temperature (K): 6500

Viewing Angle (H/V) (°): 140/120

Weight & Dimensions


Panel Dimensions: 500×500×100mm

Panel Weight: 9.3kg / 20.46lbs

Module Dimensions: 250×250mm

Power & Current


Operating Voltage: 100-240VAC

Max Power Consumption (W/m2): 540W

Electronics Service: Front/Rear

Backbox Design: Modular

Power: Seetronic® Powerkon IP65 in/out

Data: Seetronic® Etherkon IP54 in/out

Warranty


2-year limited warranty with two business day turnaround on LED repairs and most module repairs that don’t require module replacement. For most electronic issue, Blizzard will ship you a new one within 24 business hours.

Downloads

  • Cutsheet

    Download

    iris-ip3_cutsheet.pdf
