G-Max™ 200

200W LED Spot Moving Head Fixture

$1,749.99

G-Max™ 200 Buy

200W LED Moving Spot

G-Max™ 200 is an LED moving head that boasts some serious power with its extremely bright, 200W LED light engine, and it's 13°- 27° motorized zoom is perfect for short or long throws. It is equipped with ultra-fast 3-phase pan/tilt motors plus an 8 color + open color wheel, 7x static metal gobos +open, and 7x rotating glass gobos +open which can create amazing gobo morphing effects and mid-air projections.

Fully Loaded

It also offers a motorized linear iris, focus, and frost, plus it has two rotatable prism settings with 6-facet linear, and 8-facet prism effects with variable speed and direction control that can create a stunning aerial display. All of these professional features can be easily controlled by using either of its well-structured 16/19-channel DMX modes, or accessed directly by using its easy-to-use 5-button LCD control panel.

Main Features

* 200W white LED light engine, 60,000 hours

* Fast and precise zoomable beam angle (13°- 27°)

* 8-16 bit smooth pan and tilt resolution

* Pan: 540°/ Tilt: 230° with 3-phase motors

* 8 colors + open color wheel

* 7 metal gobos + open

* 7 rotating, indexable and replaceable gobos + open

* Smooth dimmer from 0 - 100%

* 6 linear + 8-facet prisms with variable speed and direction

* Motorized linear iris, focus, and frost

* Linear electronic focus

* Dual omega brackets with 1/4-turn fasteners

Product Specifications

Overview


38,405 Lux @ 2.5M (narrow), 13,058 Lux @ 2.5M (wide)

9,937 Lux @ 5M (narrow), 3,241 Lux @ 5M (wide)

4,668 Lux @ 7.5M (narrow), 1,543 Lux @ 7.5M (wide)

2,746 Lux @ 10M (narrow), 916 Lux @ 10M (wide)

Optical


200W white LED light engine, 60,000 hours

Fast and precise zoomable beam angle (13°- 27°)

Flicker-free LED

Weight & Dimensions


14.96" x 9.8" x 21.7" (380 x 247 x 550 mm)

48.5 Lbs. (22kg)

Control


Protocol: USITT DMX-512

3/5-pin DMX in/out

DMX channels: 16/19-channel modes

Easy-to-use 5-button control panel with LCD display

Operating modes: DMX512, master/slave, auto mode

Power & Current


90-250VAC, 50-60 Hz

Power Consumption: 283W, 2.49A, PF: .99

PowerCON™ TRUE1-compatible AC power In/Out connectors

Warranty


2-year limited warranty

Downloads

  • Cutsheet

    Download

    g-max-200_cutsheet.pdf

  • Manual
    Rev A

    Download

    g-max-200_manual_rev_a.pdf
