LB PAR™ Quad RGBA

Packed with Goodies, Like Mom Used to Pack Your Lunch Box

$199.99

https://ggdev10.com/blizzard-stash/published/360_assets/LB-Quad-RGBA/LB-Quad-RGBA.xml

Tough Little Guys

Meet our tough RGBA 4-in-1 fixture, the LB PAR™ Quad RGBA! Whether you are a mobile DJ, in a band, or just want quality lighting for any permanent installation, these fixtures are specifically designed to keep up with rigorous demands of road life and heavy usage. The LB PAR™ Quad RGBA has oodles to offer from its 12x high-output 10W RGBA 4-in-1 LEDs to its stunning physical features which include a very durable, scratch resistant composite housing and dual mounting brackets for flexible positioning.

Loaded With Features

All the features one can hope for are loaded into the LB PAR™ Quad RGBA, including 12 incredible built-in programs with auto mode, sound active mode, strobe effects, and 16-bit or 3 user selectable 32-bit dimming curve options. It can perform full RGBA color mixing with 4/9-channels of DMX, or simply be controlled via its easy-to-use 4-button LED control panel. The LB PAR™ Quad RGBA also comes with equipped with powerCON® compatible AC in/out and DMX in/out jacks.

Main Features

* 12 x 10-watt, 4-in-1 RGBA LEDs * User selectable 4/9 DMX channels * Full color mixing in standalone, master/slave and DMX modes * Built-in automated programs via master/slave * Built-in sound activated programs via master/slave * Easy to use LED digital control panel * 16/32-bit dimming modes * 3-pin male input and 3-pin female output * Dual mounting yoke allows flexibility in positioning * Durable, scratch resistant composite housing * powerCON® compatible AC in/out

Product Specifications

Optical

Light source: 12 x 10-watt, 4-in-1 RGBA LEDs

Beam Angle: 25°

Luminous Intensity: 17,000 Lux @ 1m / 5,260 Lux @ 2m

Weight & Dimensions

Length: 11 inches (28 cm)

Height: 10.5 inches (25.4 cm)

Width: 4.25 inches (10.8 cm)

Weight: 5 lbs (2.3kg)

Control

Protocol: USITT DMX-512

DMX Channels: 4/9 (User Selectable)

Input: 3-pin XLR Male

Output: 3-pin XLR Female

Operating Modes: Standalone, Master/Slave, Sound Active, Color Preset

Power & Current

Operating Voltage: 100-240VAC, 50-60 Hertz

Power Consumption: 73W, .64A, PF: .99

Warranty

2-year limited warranty, does not cover malfunction caused by damage to LEDs

Downloads

  • Cutsheet

    Download

    lb-par-quad-rgba_cutsheet.pdf

  • Manual
    Rev A

    Download

    lb-par-quad-rgba_manual_rev_a.pdf

  • Manual
    Rev B

    Download

    lb-par-quad-rgba_manual_rev_b.pdf
