ToughStick™ RGBAW
Herculean Style
ToughStick™ RGBAW
Herculean Style
$599.99
* RGBAW color mixing via 60x 3W Red/Green/Blue/Amber/White LEDs
* Variable electronic strobe
* Variable electronic dimmer
* Built-in color & chase macros via DMX
* Built-in automated programs via master/slave
* RGBAW color mixing ability in standalone mode
* Independent control of 3 pixels (20 LEDs each)
* User selectable 4/5/6/10/16/20-channel DMX modes
* Easy to use LED control panel
Where Else to Buy
Usually Ships Same Day
Tested for Quality
Overview
Specs
Downloads
Photometric
Stellar Color Mixing
The ToughStick RGBAW™ is a tough combination outdoor rated RGBWA strip wash / pixel / effect fixture powered by 60x 3W Red/Green/Blue/Amber/White LEDs (12x each). Users can produce stellar color mixing from its high powered RGBWA LEDs, plus full independent control of 3 individual pixels (20x LEDs each).
Full Control
User selectable 4/5/6/10/16/20-channel DMX modes and an LED control panel make this fixture flexible and easy to use, and built in color change and pixel chase programs are available in standalone, master-slave, and DMX modes for ultimate versatility. It’s built like a brick with a heavy-duty anodized aluminum enclosure, tempered glass top, extended waterproof AC power and 3-pin DMX connections. Cherry on top? The adjustable dual mounting brackets make for total positioning flexibility!
Main Features
* RGBAW color mixing via 60x 3W Red/Green/Blue/Amber/White LEDs
* Variable electronic strobe
* Variable electronic dimmer
* Built-in color & chase macros via DMX
* Built-in automated programs via master/slave
* RGBAW color mixing ability in standalone mode
* Independent control of 3 pixels (20 LEDs each)
* User selectable 4/5/6/10/16/20-channel DMX modes
* Easy to use LED control panel
Product Specifications
Optical
Light source: 60x3W (12x R,G,B,A,W) 100,000 hours
Beam Angle: 25 degree
Luminous Intensity: 11,000 Lux @ 1m, 5,200 Lux @ 2m
Weight & Dims
Length: 39.45 inches (1002 mm)
Width: 4.33 inches (110 mm)
Height: 6.69 inches (170 mm)
Weight: 13.23 lbs (6 kg)
Control
Protocol: USITT DMX-512
DMX Channels: 4/5/6/10/16/20-channel
Input: 3-pin XLR Male
Output: 3-pin XLR Female
Other Operating Modes: Standalone, Master/Slave
Power & Current
Operating Voltage:100V-240VAC, 50-60 Hertz
Fuse: 3A
75w, 2.04A
Power Factor: .63
Warranty
2-year limited warranty, does not cover malfunction caused by damage to LEDs
