Narrow (5°)

Wide (45°)


28,180 Lux

2,458 Lux


6,517 Lux

425 Lux


1,700 Lux

130 Lux



Nudge-nudge, wink-wink!



Zoom + LED Ring Effects

Wink™ is a powerful LED moving head fixture that comes loaded with features such as a high-output 60W 4-in-1 RGBW LED in the center with 5-45° motorized zoom for exceptionally bright wide/narrow beams, plus a 4* segment (pixel mappable) LED ring with a total of 8x 0.5W RGB LEDs for extra cool eye candy effects.

Infinite Pan and Tilt

Users can shake things up with Wink’s blazing fast 540°/270° pan and tilt, or even mind-blowing unlimited movement thanks to its incredible infinite pan and tilt rotating abilities. It also offers 2 auto modes, 2 sound active modes, multiple color presets, virtual color wheel effects, 4-button TFT LCD display, 3-pin DMX In/Out, powerCON™ compatible power In/Out, and a single ¼ turn omega mounting bracket.

Main Features

* 1x 60W RGBW high-output 4-in-1 LED * 4-segment RGB colored ring with 8x 0.5W RGB 3-in-1 LEDs * Individual pixel and LED ring control * 5-45 degree zoomable beam angle * 540°/270° tilt + infinite pan and tilt * Fast Pan/tilt motors with 16-bit resolution * Built-in auto and sound active programs * Multiple static color presets and virtual color wheel * Variable electronic dimming & strobe effects (1-20Hz) * Flicker-free constant-current LED driver * 3-pin male input and 3-pin female output * PowerCON™ compatible AC power In/Out connectors * Protocol: USITT DMX-512 * 19/26/35-channel DMX modes * 2.4 inch TFT color LCD display with 4x touch sensitive buttons

Product Specifications


1x 60W RGBW 4-in-1 LED + 8* 0.5W RGB 3-in-1 LEDs (Ring)

Beam Angle: 5°- 45°

Luminous Intensity:
6,517 Lux @ 2.5m (5°)
425 Lux @ 2.5m (45°)
1,700 Lux @ 5m (5°)
130 Lux @ 5m (45°)


Pan: 540 degree (8-16 bit resolution)

Tilt: 270 degree (8-16 bit resolution)

Infinite pan and tilt

Weight & Dimensions

Width: 8.3” (210 mm)
Depth: 6.5” (164 mm)
Height: 12.1” (306.6 mm)

Weight: 12.5 lbs. (5.7 kg)


Protocol: USITT DMX-512

19/26/35-channel DMX modes

Standalone, master/slave, auto, sound active

3-pin XLR In/Out connections

4-button LCD control panel

Power & Current

100-240VAC, 50-60 Hz

Power Consumption: 110W, 1.44A, PF: .66
