HotBox™ EXA


SKU: 123530

  • RGBAW+UV color mixing via 7x 15W 6-in-1 LEDs
  • Variable electronic dimming & strobe
  • 5 user-selectable 32-bit dimming curves
  • Built-in color & chase macros via DMX
  • Built-in automated programs via master/slave
  • Built-in sound active programs
  • Color mixing ability in standalone mode
  • Rugged and well-built (It hits the gym regularly)
  • Super-quiet variable-speed internal fan cooling
  • Dual mounting brackets for positioning flexibility
  • Flicker-free constant-current 400hz LED driver
  • 3-pin male input and 3-pin female output
  • powerCON® compatible AC power In/Out connectors
Fast, Free Shipping on Orders $99+
- +
Add to Cart
Where Else to Buy

Suggested Products

Wi-Fi based sACN/Art-Net to DMX

Learn More

30W, 9+ Colors/Gobos, Ring Effects

Learn More

Control HotBox™ EXA with your mobile device

Learn More

Product Summary

HotBox EXA fixtures offer 7x 15W 6-in-1 RGBAW+UV LEDs, advanced electronics, and a rock-solid aluminum casing with dual hanging brackets, all wrapped up in a cute little package. It weighs in at just 3.5 pounds and is only 4 x 5 x 5 inches (7.25 inches tall including the brackets.)

It puts out a ton of light, and its user selectable 3/6/8/10 or 11 DMX channel modes allow them to work great with any type of controller. It offers RGBAW+UV color mixing, multiple built-in programs, flicker-free 32-bit dimming, and even easy HSV color mixing ability in 3-channel DMX mode.



Light source: 7x 15W 6-in-1 LEDs 100,000 hours

Beam Angle: 25 degree optics standard, 26 degree beam, 30 degree field

Luminous Intensity: 11,250 Lux @ 1M, 3,150 Lux @ 2M


Protocol: USITT DMX-512

DMX Channels: 3/6/8/10/11

Input: 3-pin XLR Male

Output: 3-pin XLR Female

Operating Modes: Standalone, M/S, Sound Active, Color Preset


Operating Voltage: 100-264VAC, 47-63 Hz

Fuse: 2A 250V

Power Consumption: 58W


2-year limited warranty

Dims & Weight

5" L x 4" W x 5" H

3.5 lbs
