LB PAR™ Hex
Packed with Goodies, Like Mom Used to Pack Your Lunch Box
LB PAR™ Hex
Packed with Goodies, Like Mom Used to Pack Your Lunch Box
$249.99
* 12 x 15-watt, 6-in-1 RGBAW + UV LEDs
* User selectable 6/11 DMX channels
* Full color mixing in standalone, master/slave and DMX modes
* Built-in automated programs via master/slave
* Built-in sound activated programs via master/slave
* Easy to use LED digital control panel
* 16/32-bit dimming modes
* 3-pin male input and 3-pin female output
* Dual mounting yoke allows flexibility in positioning
* Durable, scratch resistant composite housing
* powerCON® compatible AC in/out
Where Else to Buy
Tested for Quality
Overview
Specs
Downloads
Photometric
Tough Little Guys
Meet our incredible 6-in-1 LED fixture, the LB PAR™ Hex! With 12x totally bright 15-watt RGBAW+UV 6-in-1 LEDs, LB PAR™ Hex fixtures give you the ability to create any rich, vibrant color you can possibly imagine, plus the option to throw some ultraviolet light into the mix to give off an eerie hue. The cherry on top? These fixtures are solidly built units with durable scratch resistant composite housing and dual mounting brackets for flexible positioning.
Loaded With Features
All the features one can hope for are loaded into the LB PAR™ Hex, including 12 incredible built-in programs with auto mode, sound active mode, strobe effects, 8-bit or 3 user selectable 32-bit dimming curve options. It can perform full RGBAW+UV color mixing with 6/11-channels of DMX, or simply be controlled via its easy-to-use 4-button LED control panel. The LB PAR™ Hex also comes with equipped with powerCON® compatible AC in/out and DMX in/out jacks.
Main Features
* 12 x 15-watt, 6-in-1 RGBAW + UV LEDs
* User selectable 6/11 DMX channels
* Full color mixing in standalone, master/slave and DMX modes
* Built-in automated programs via master/slave
* Built-in sound activated programs via master/slave
* Easy to use LED digital control panel
* 16/32-bit dimming modes
* 3-pin male input and 3-pin female output
* Dual mounting yoke allows flexibility in positioning
* Durable, scratch resistant composite housing
* powerCON® compatible AC in/out
Product Specifications
Optical
Light source: 12 x 15-watt, 6-in-1 RGBAW + UV LEDs
Beam Angle: 25°
Luminous Intensity: 8,000 Lux @ 1m
Weight & Dims
Length: 11 inches (28 cm)
Height: 10.5 inches (25.4 cm)
Width: 4.25 inches (10.8 cm)
Weight: 5 lbs (2.3kg)
Control
Protocol: USITT DMX-512
DMX Channels: 6/11 (User Selectable)
Input: 3-pin XLR Male
Output: 3-pin XLR Female
Operating Modes: Standalone, Master/Slave, Sound Active, Color Preset
Power & Current
Operating Voltage: 100-240VAC, 50-60 Hertz
Power Consumption: 106W, .88A, pf .99
Warranty
2-year limited warranty, does not cover malfunction caused by damage to LEDs
